- High quality imaging with 8 MP resolution. Efficient H.265 compression technology.
- Clear imaging against strong back light due to 130 dB WDR technology.
- Smart AI support Line crossing, intrusion, region entrance, region exiting. Supports human and vehicle targets classification.
- 24/7 colorful imaging. Built-in memory card slot, support microSD/microSDHC/microSDXC/TF card, up to 512 GB
- Built-in microphone for real-time audio security.
Camera
Image Sensor:1/1.2" Progressive Scan CMOS
Frame Rate: 50 Hz 25fps (3840 × 2160)
Signal System:PAL/NTSC
Shutter time:1/3 s to 1/100,000 s
Slow shutter:Support
Lens:2.8 mm, horizontal field of view: 102°
Lens Mount:M12
Day& Night:IR cut filter with auto switch
IR Range:Up to 40m
Wide Dynamic Range:130 dB
Digital noise reduction:3D DNR
Enhanced IR Technology
Up to 30% more illumination
Static protection
Longer lifespan
Excellent heat dissipation
Highly efficient light source
Compression Standard
Video Compression:H.265 /H.265/H.264 /H.264/MJPEG
Video bit rate:32Kbps~16Mbps
Triple Streams:Yes
Image Enhancement:BLC/3D DNR
Image Settings:Rotate Mode, Saturation, Brightness, Contrast, Sharpness adjustable by client software or web browser
ROI:Support 1 fixed region for main stream and sub stream separately
Day/Night Switch:Auto/Scheduled
Network
Function:One-key reset, Anti-Flicker, heartbeat, mirror, password protection, privacy mask, Watermark, IP address filtering
Interface
Communication Interface:1 RJ45 10M / 100M Ethernet interface
On-board storage:Built-in Micro SD/SDHC/SDXC slot, up to 512 GB
Smart Feature-set
Behavior Analysis:Line crossing detection, Intrusion detection
Line Crossing Detection:Cross a pre-defined virtual line
Intrusion Detection:Enter and loiter in a pre-defined virtual region
Recognition:Face Detection
